Features
All performance indexes meet the primary working machine requirements of metrological verification procedures of national standard JJG696-2002;
Apply on paint, ink, stoving varnish, coating, wood products; Marble, granite, vitrified polished tile, pottery brick and porcelain; Plastic, paper and metal,etc;
International Standard 60° ISO－2813、ASTM－C584、ASTM－D523、DIN－67530、ASTM－D2457、JND-A60、JND-P60;
Multi-measurment mode: Measuring Mode Automatic measurement/ manual measurement/single measurement/average measurement and basic/statistic measurement.

Specification
Model WG60
Measurement Range 0-200Gu
Application Apply on paint, ink, stoving varnish, coating, wood products; Marble, granite, vitrified polished tile, pottery brick and porcelain, plastic, printing, paper; other metallic material.
Instrument Dimensions 122x34x63.6mm
Projection Angle 60°
Measuring Spot（ellipse: long axis*minor axis）15mm*9mm
Measuring Mode Automatic measurement/ manual measurement/single measurement/average measurement and basic/statistic measurement
Standard Sample Setting Manually setting standard and tolerance to determine “pass” or “failure”.
Data Storage 100 groups, set standard sample in any stored data, user-define the tolerance range
Language Chinese/English
Software Yes
Division Value 0.1Gu
Repeatability 0.2Gu
Reproducibility 0.4Gu
Indication Error 1.0Gu
International Standard 60°
ISO－2813、ASTM－C584、ASTM－D523、DIN－67530、ASTM－D2457、JND-A60、JND-P60
National Standard 60° GB 9754、GB 9966、GB 8807
Standard Accessories Type C cable/Power adapter/user manual/warranty certification/standard calibration board
