Introduction

The Colorimeter is a professional colorimeter designed and produced subject to the relevant standards of International Commission on Illumination (CIE) and national stands. Being with brand new imported key components, the instrument is well designed and features in precision, stability, easy handling, easy to learn and cost-effective.

The instrument applies to the color quality control, color difference control, color difference analysis, sampling testing and online testing for industries as textile, printing and dyeing, garments, shoes, leather, chemical, plastic, pigment, paint, ink, printing, metal, photography and toys etc., as well as to the auxiliary color matching during the processes as injection, inking, painting and spraying coating etc.

Aperture 8mm version is a general-purpose color difference meter, mostly used on flat surface materials. It provides great convenience and trustworthy reliability for its versatility, tiny table difference and stability.

Features

1. Convenient: automatic correction when starting up, no need to do calibration manually each time. (national patent).

2. Comfortable: observation with real color screen display, handheld and exquisite.

3. Cost-efficient: good performance, stable measurement, low cost.

4. Configuration: rechargeable, high capacity lithium battery.

5. CE & RoHS certification.

Specification

Model: WR-10

Color Space: CIE-Lab、CIE-LCh、Luv、Hunter-Lab、XYZ、Yxy、sRGB

Color Difference Formula: △E*ab、△E*ch、△E*uv、△E*HunterLab、△E*CMC(I:c)、△E*94、△E*00、△E*sRGB、△E*BFD、△E*FCMII

Light Source: A、C、D50、D55、D65、D75

 Aperture: φ8mm

Geometry: d/8, 40mm integrating sphere, SCI

Light: Full spectrum LED

Resolution: 0.01

Sensor: Silicon solar cell array

Observer: 10°CIE1964 / 2°CIE1931

Wavelength: 400-700nm, interval: 10nm

Reflectivity: 0-200%, accuracy: 0.01%

Measurement Range: L: 0 to 100

Repeated Accuracy: △E<0.05

Table Difference: △E<0.4

Test speed: 1.0Sec.

Storage Capacity: 10000 data

Lifetime of Bulb: 5 years more than 1.6 million measurements

Interface: Type C/Bluetooth

Software: Android/iOS/Windows

Working Temperature: 0℃-40℃（32℉-104℉）

Storage Temperature: -20℃-50℃（-4℉-122℉）

Humidity: Relative humidity less than 85%,without condensation

Weight: 700g

Size: 199*68*90mm

Battery Charging Time: 8 hrs

Battery: Polymer battery, 1000 times tests for full charged

Standard Accessories: Instrument/Calibration board/Type C cable/Charger/User manual/Warranty card
