Introduction

SA series spectrophotometer is a spectrophotometer newly developed by FRU.There are two versionsfor customers to choose.

SA series spectrophotometer adopts long life and low power consumption.

Full spectrum combined LED light source and dual optical path array sensor,stable performance andaccurate measurement.

It has powerful functions and can be widely used in various fields such as paint,plastic,resin,textile,leather,etc.,to help you achieve ideal color control.

Features

High precision spectral structure

Convenient to carry

Full spectrum combination light source

White porcelain callbration board

Specification

Model SA23

Aperture 8mm

SCl

Light type High Accuracy full spectrum LED

Fix position Visual

Repeated Accuracy △E≤0.04

Color space CIE-Lab,CIE-LCh,Luv,Hunter-Lab,XYZ,Yxy,sRGB,DIN LAB99,CMYK(A/T/E/M/l),Field density,Munsell,Rellectance (bright vision),Blackness,Yl yellow,Isochromatic spectrum (light jumping),hiding power,tint/strength/dye,Color fastness,Taube whiteness,Berger whiteness,Tappi whiteness,Cros whiteness,Stephansen whiteness,Ganz whiteness,Hunte whiteness (ASTM),Whiteness (CIE),AATCC whiteness,R457/1SO2470 whiteness,GB/T17644 whiteness

Color difference fomula △E*ab、AE*ch、AE*uv、AE*HunterLab、AE*CMC(l:c)、AE*94、AE*00、AE*sR GB、

AE*BFD、M*FCMII、AE*DIN99

Light source A、C、D50、D55、D65、D75、F1、F2、F3、F4、F5、F6、F7、F8、F9、F10、F11、F12、

CWF、U30、U35、DLF、NBF、TL83、TL84

Observer 10°(CIE1964)2°(CIE1931)

Wave length 400-700nm 10nm interval

Reflectivity Range: 0-200% Resolution: 0.01%

Sensor CMOS sensor

Geometric D/8 40mm integrating sphere

Callbration Default: Automatic

Display Resolution 0.01

Table ditlerence △E*ab≤0.25

Test speed 1.0s

Display 3.5 inch full color capacitive touch screen

Language 简体中文，繁体中文，English

Power Polymer Li-ion battery 10000 times full

Interface Type C Bluetooth

App platfom Andorid lOS Windows

Storage 8000 group Mass storage for APP

Slze 181x67x67mm(without base)

N.W/G.W 330g/1200g

Packing list Instrument, calibrate base, type C charger, user manual, warranty card, single aperture
